Introduction
The EN standards for stainless steel are quite complex and it is sometimes hard to know which standards you need to know about in order to fulfil all the requirements of an order. This article is an attempt to simplify the path through the maze of standards that now exists.
It is worth remembering that the following topics are usually covered in separate standards:
· Compositions and Properties
· Tolerances
· Test Methods
· Product Form Definitions
The logic of this approach is that a change to one aspect of a product does not lead to a change in all the others. However, it does mean that the user may have to follow a chain of references between standards. There are also some links to articles on this website dealing with the relevant standard
Summary of Standards
StandardProduct FormRelated StandardsSubject
EN 10088-2FlatEN 10088-2Chemical Compositions
EN 10088-2Mechanical properties austenitic steels
EN 10088-2Mechanical properties ferritic steels
EN 10088-2Mechanical properties martensitic steels
EN 10088-2Mechanical properties duplex steels
EN 10088-2Mechanical properties PH steels
EN 10258Tolerances for narrow cold rolled strip
EN 10259Tolerances for wide cold rolled strip/sheet/coil
ISO 9444Tolerances for hot rolled coil/sheet
ISO 9445Tolerances for all cold rolled products
ISO 18286Tolerances for quarto Plate
EN 10079Definition of product forms
EN 10002Tensile test methods
EN 10045Impact test methods
EN 10163-2Surface condition of hot rolled flat products
EN 10168Inspection documents
EN 10204Types of inspection documents
EN 10307Ultrasonic testing of flat products
EN ISO 377Test piece sampling
EN ISO 3651-2Intergranular corrosion testing
EN ISO 6506-1Brinell hardness testing
EN ISO 6507-1Vickers hardness testing
EN ISO 6508-1Rockwell hardness testing
EN ISO 14284Sampling for chemical composition testing
EN 10088-3Long EN 10088-3Chemical Compositions
EN 10088-3Mechanical properties austenitic steels
EN 10088-3Mechanical properties ferritic steels
EN 10088-3Mechanical properties martensitic and PH steels
EN 10088-3Mechanical properties duplex steels
EN 10088-3Mechanical properties austenitic bright bar
EN 10088-3Mechanical properties ferritic bright bar
EN 10088-3Mechanical properties martensitic and PH bright bar
EN 10088-3Mechanical properties duplex bright bar
EN 10058Tolerances for hot rolled flat bar
EN 10059Tolerances for hot rolled square bar
EN 10060Tolerances for hot rolled round bar
EN 10061Tolerances for hot rolled hexagon bar
EN 10278Tolerances on bright steel products
EN 10017Tolerances on wire rod
EN 10218-2Tolerances on wire
ISO 286-1System of limits and fits
EN 10079Definition of product forms
EN 10002Tensile test methods
EN 10045Impact test methods
EN 10163-3Surface condition of sections
EN 10168Inspection documents
EN 10204Types of inspection documents
EN 10306Ultrasonic testing of H beams and IPE beams
EN 10308Ultrasonic testing of bars
EN ISO 377Test piece sampling
EN ISO 3651-2Intergranular corrosion testing
EN ISO 6506-1Brinell hardness testing
EN ISO 6507-1Vickers hardness testing
EN ISO 6508-1Rockwell hardness testing
EN ISO 14284Sampling for chemical composition testing
EN 10296-2Welded TubeEN 10296-2Chemical Compositions
EN 10296-2Mechanical Properties
EN ISO 1127 Tolerances. However, some tolerances are also covered within EN 10296-2 itself
EN 10079 Definition of product forms
EN 10002 Tensile test methods
EN 10246-2Eddy current testing for leak tightness
EN 10246-3Eddy current testing for detection of imperfections
EN 10246-7Peripheral ultrasonic testing for detection of longitudinal imperfections
EN 10246-8Weld seam ultrasonic testing for detection of longitudinal imperfections
EN 10246-9Weld seam ultrasonic testing of submerged arc welded tubes for detection of longitudinal/transverse imperfections
EN 10246-10Weld seam radiographic testing for detection of imperfections
EN ISO 8491Bend test for tubes
EN ISO 8492Flattening test for tubes
EN ISO 8493Drift expanding test for tubes
EN ISO 8496Ring tensile test for tubes
EN ISO 377 Test piece sampling
EN ISO 3651-2 Intergranular corrosion testing
EN 10297-2Seamless TubeEN 10297-2Chemical Compositions
EN 10297-2Mechanical Properties
EN ISO 1127 Tolerances. However, some tolerances are also covered within EN 10297-2 itself
EN 10079 Definition of product forms
EN 10002 Tensile test methods
EN 10246-2Eddy current testing for leak tightness
EN 10246-3Eddy current testing for detection of imperfections
EN 10246-5Peripheral MPI testing for detection of longitudinal imperfections
EN 10246-7Peripheral ultrasonic testing for detection of longitudinal imperfections
EN ISO 377 Test piece sampling
EN ISO 3651-2 Intergranular corrosion testing
